Componenti minimi
1 manopola.
1 coperchio.
1 set per variante di montaggio a filo.
System components to complete

B8633008
Cover 33volcano

B8633009
Cover 33nero

B8633108
Supply 1 cover
ChiudiB8633108
Cover 33, with finger recessvolcano

B8633109
Supply 1 cover
ChiudiB8633109
Cover 33, with finger recessnero

B8733118
Supply 1 assembly kit
ChiudiB8733118
Assembly kit 33, flush fitting versionvolcano

B8733119
Supply 1 assembly kit
ChiudiB8733119
Assembly kit 33, flush fitting versionnero
Accessory "illumination"

B7546001
Board D=27 mm with 8 LEDs (RGB backlight), without controller, SMD technology, connecting cable 120 mm long, 4-pin socket at the end, incl. connector.
Recommended for:STAR-KNOBS 33 / 41
- flush-fitting version: only in conjunction with the diamond knob
- surface-mounted version: only in conjunction with the diamond assembly kit
CONTROL-KNOBS 36 with optional illumination
- installation in the bases available as accessories
Supply 1 LED illumination kit (RGB backlight)
ChiudiB7546001
LED illumination kit, 8 LEDs (RGB backlight)Accessory

A6207009
For fixing the potentiometers at front panels.
Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.
Supply 1 round nut
ChiudiA6207009
Round nut M7 x 0.75
A6210009
For fixing the potentiometers at front panels.
Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.
Supply 1 round nut
ChiudiA6210009
Round nut M10 x 0.75
A6295009
Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.
Supply 1 round nut
ChiudiA6295009
Round nut 3/8"-32G
A6300000
Supply 1 spanner
ChiudiA6300000
Spanner
B8733001
Supply 1 assembly support
ChiudiB8733001
Assembly support 33green
